BK-81 General: Heavy-duty truck mounted drill rig for soil and rock exploration using augers, rotary or core drilling tools. This rig is mounted on a 2003 Sterling truck. Power Unit: John Deere 359 CID (5.9L) 165 hp liquid cooled 6 cyl. Turbo Diesel. Spindle: Heavy-duty 20,000 lbs/ft. Thrust-down - 16,640 lbs@ 2000 psi. Thrust-up - 28,280 lbs@ 2000 psi.
Mast Clearance: Mast down drilling 21' - Mast up drilling 35' Slide Base: In/Out 18" Side to side 12" |
||||||||||||||
D120 General: Heavy-duty truck mounted drill rig for soil and rock exploration using augers, rotary or core drilling tools. Power Unit: Deutz F6L-912 Industrial Diesel
Spindle: Heavy-duty 12,570 lbs/ft. Thrust-up 30,000 lbs/ft @ 2000 psi. Thrust-down 20,200 lbs/ft @ 2000 psi. Mast Clearance: Mast down drilling 17' Mast up drilling 30' Slide Base: In/Out 18" Side to side 12" |
||||||||||||||
CME-750 All-Terrain Drill Rig General: The CME-750 is a multi-use core and auger drill and all-terrain 4-wheel drive carrier with large floatation tires. The drill is specifically designed for conventional and hollow auger drilling, split spoon sampling, thin wall tube sampling, core and rotary drilling. The carrier is designed to go through mud, snow, sand, steep slopes, uneven ground and wooded areas.
Capacity: Auger drilling, Conventional and hollow, to depths of up to 300 feet w/up to 16" borehole. Core and Rotary drilling to depths of up to 1650 feet, w/NW drill rods. Power Unit: Power for the drill and carrier is furnished by a 300 cubic inch Ford, 6-cyl. liquid-cooled gasoline industrial engine, and a Deutz F6L-912 cubic inch 6-cyl. air-cooled diesel engine. The engine is equipped with a 12-volt electrical system and a 20 gallon fuel tank. |
||||||||||||||
 |
||||||||||||||
Geoprobe 5400 |
||||||||||||||
3 - Geoprobe 6620 DT |
||||||||||||||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
